JK8750C-13095 Oil-free automatic pattern template sewing machine with rotary head

Short Description:

1. Supports the installation of additional functions such as laser cutting and air suction devices; no need to repeatedly purchase multiple types of machines; reduces cost input.

2. Featuring a rotating machine head paired with dual synchronous belt transmission, the system adapts effortlessly to patterns of varying angles and shapes—overcoming the directional constraints of conventional sewing equipment.

3. With 360 ° all-directional sewing capability, the JK8750C series transcends the operational limits of traditional machines.

4. Standard equipped with electronic middle presser foot, which varies up and down along with the thickness of the fabric.

5. With various function, it can replace machines such as pattern machines and pocket welting sewing machines.

6. No need for skilled worker, save labor costs; Increase efficiency by at least 10%.

7. Standardized production, unified and beautiful finished product.


  • Payment term:: T/T, L/C
  • Port:: Ningbo/Shanghai
  • Product Detail

    Product Tags

    Model JK8750C-13095 JK8750C-13095/J
    Sewing range(mm) 1300(X)×950(Y)mm
    Tabletop size 2100×2475mm
    Laser cutting range 1020×950mm
    X-beam 1600/1800mm
    Auxiliary plate 800/1000mm
    Stitch type Single-needle 301 lockstitch form
    Max. speed 3600rpm/min
    Stitch length 0.5-12.7mm
    Needle type DB×1 (#8)  7#-14#
    Hook type Full-rotation 2-fold rotating hook
    Intermediate presser foot adjustment range Lifting amount: 20mm Stroke: Standard 4mm
    Program input method USB
    File format DXF AI PLT DST etc.
    Template holding mode Pneumatic clip type or compression type
    Voltage 220V
    Air pressure 0.4-0.6MPa
    Power 750W 850W
    Weight(G.W/N.W)/kgs 788/677 850/739
    Packing size(mm) 2100×1200×1770(L×W×H)
