JK8310C-13085 Oil-free automatic pattern template sewing machine

Short Description:

1. Supports the installation of additional functions such as laser cutting, rotating cutters and air suction devices; no need to repeatedly purchase multiple types of machines; reduces cost input.

2. X-Y drive mode: Dual synchronous tape transfer.

3. Standard equipped with electronic middle presser foot, which varies up and down along with the thickness of the fabric.

4. Meet the processing needs of larger-sized workpieces:

·The X-axis beam can be extended from 850mm to a maximum of 1600mm

·The installation of auxiliary plates increases the effective bearing area of the table.

5. With various function, it can replace machines such as pattern machines and pocket welting sewing machines.

6. No need for skilled worker, save labor costs; Increase efficiency by at least 10%.

7. Standardized production, unified and beautiful finished product.

Payment term:: T/T, L/C

Port:: Ningbo/Shanghai

Send email to us

Product Detail

Product Tags

Model	JK8310C-13085	JK8310C-13085/J	JK8310C-13085/QX
Sewing range	1300(X)×850(Y)mm
Tabletop size	2100×2193mm
Laser cutting range	1140×770mm
Knife cutting range	1190×770mm
X-beam	Longest 1600mm
Auxiliary plate	800/1000mm
Stitch type	Single-needle 301 lockstitch form
Max. speed	3600rpm/min
Stitch length	0.5-12.7mm
Needle type	DB×1 (#8) 7#-14#
Hook type	Full-rotation 2-fold rotating hook
Intermediate presserfoot adjustment range	Lifting amount: 20mmStroke: Standard 4mm
Program input method	USB
File format	DXF AI PLT DST etc.
Template clamping method	Pneumatic clip type or compression type
Voltage	220V
Air pressure	0.4-0.6MPa
Power	750W	850W	850W
Weight(G.W/N.W)/kgs	620/505	680/565	620/505
Packing size(mm)L×W×H	1880×1300×1300	1880×1300×1470	1880×1300×1300
