JK8130C-8045 Automatic pattern template sewing machine

Short Description:

1. Supports the installation of additional functions such as laser cutting, rotating cutters and air suction devices; no need to repeatedly purchase multiple types of machines; reduces cost input.

2. X-Y drive mode: Dual synchronous tape transfer.

3. Standard equipped with electronic middle presser foot, which varies up and down along with the thickness of the fabric.

4. Compact size, excellent space adaptability.

5. With various function, it can replace machines such as pattern machines and pocket welting sewing machines.

6. No need for skilled worker, save labor costs; Increase efficiency by at least 10%.

7. Standardized production, unified and beautiful finished product.

Payment term:: T/T, L/C

Port:: Ningbo/Shanghai

Send email to us

Product Detail

Product Tags

Model	JK8130C-8045	JK8130C-8045/J	JK8130C-8045/QX	JK8130C-10045
Sewing range(mm)(X×Y)	800×450			1000×450
Tabletop size	1200×1325mm
Laser cutting range	640×420mm
Knife cutting range	690×390mm
X-beam	100cm
Stitch type	Single-needle 301 lockstitch form
Max. speed	3600rpm/min
Stitch length	0.5-12.7mm
Needle type	DB×1 (#8) 7#-14#
Hook type	Full-rotation 2-fold rotating hook
Intermediate presser foot adjustment range	Lifting amount: 20mmStroke: Standard 4mm
Program input method	USB
File format	DXF AI PLT DST etc.
Voltage	220V
Air pressure	0.4-0.6MPa
Power	550W	650W	650W	Variable
Weight(G.W/N.W)/kgs	390/325	450/385	390/325	Variable
Packing size(mm)L×W×H	1530×1330×1300	1530×1330×1470	1530×1330×1300	Variable
